General Specifications
|
| Description/Midlands: |
Traditional touring design.
Super-long wheelbase and low bottom bracket mean stability for
long-distance loaded touring. All standard touring braze-ons. |
| Bicycle Type: |
Touring |
| Component Group: |
Shimano Sora |
| Sizes Available: |
47,
50, 50, 53, 55, 57, 59 and 62cm |
| Colors Available: |
Your choice of 10 colors |
| Weight: |
25.75 lbs |
| Price: |
$1,895 Travel Package; $1095 bike
only |
| Travel Package Option: |
Includes
an S & S torque coupler-equipped bicycle, coupler spanner,
hard shell or backpack case, Easy-Split cable disconnects,
velcro frame pads and compression struts.
|
|
|
|
Frame
|
| Frame Construction: |
Tig-welded |
| Material: |
Reynolds 520 |
| Head Tube Angle: |
72.5 degrees |
| Seat Tube Angle: |
73 degrees |
| Top Tube Length: |
21.7 inches |
| Wheelbase: |
40.4 inches |
| Chainstay Length: |
17.3 inches |
|
|
|
Fork
|
| Fork Brand & Model: |
Unicrown |
| Fork material: |
Chromoly
steel |
| Fork Rake: |
2.00 inches |
| Fork Crown: |
Unicrown |
|
|
|
Components
|
| Shift Levers: |
Shimano Tiagra STI |
| Rear Derailleur: |
Shimano Deore SGS |
| Front Derailleur: |
Shimano Sora Triple |
| Front Der' Type: |
Bottom Pull |
| Front Der' Type 2: |
28.6 clamp on |
| Brake Levers: |
Shimano Tiagra |
| Brakeset: |
Tektro Cantilevers |
| Bottom Bracket: |
Shimano cartridge |
| BB spindle length: |
115 mm |
| Chainrings |
24/36/48 |
| Crankset: |
Sugino XD |
| Number of Rear Cogs: |
9 speed |
| Smallest Rear Cog: |
11 |
| Largest Rear Cog: |
32 |
| Chain Size: |
1/2 x 3/32 |
| Chain: |
KMC HG73 |
| Headset: |
Aheadset |
| Headset Diameter: |
1 1/8" |
|
|
|
Rider's Interface
|
| Handlebar stem: |
Ritchey Comp Road |
| Handlebar: |
Ritchey Bio-max II |
| Handlebar extensions: |
Not included |
| Saddle: |
WTB Comfort V Men's and Ladies |
| Seatpost: |
Ritchey Comp microadjust |
| Seat Post Diameter: |
27.2 mm |
| Pedals: |
Alloy cage platform with toe
clips |
|
|
|
Wheelset
|
| Hubs: |
Shimano Sora |
| Spoke Type: |
Straight |
| Spoke Material: |
Stainless Steel |
| Spoke Gauge: |
14 |
| Spoke Holes: |
36 |
| Spoke Nipples: |
Brass |
| Rims: |
Alex ACE19 |
| Tire Front: |
Conti Top Touring |
| Tire Rear: |
Conti Top Touring |
| Tire Size Front: |
700 x32c |
| Tire Size Rear: |
700 x32c |
|
